NEW REMEX model paralleLathe 660-104

NEW LATHE Capacity & dimensions Overhead Above the bed 660 mm Above the cross slide 460 mm Without crane 845 mm Distance from bed to flange front 180 mm Center points Tip height 280 mm Distance between centers 2040 mm Bed Width 400 mm Length 2095 mm Main spindle motor 15HP inverter Coolant pump motor (0.1KW) 2P 3ph Head Spindle Hole 104 mm Nose D1-8” ASA std. Spindle taper Morse 8 Bushing taper to reduction Morse5 Speed Variable in 2 ranges Range Constant Torque  Constant Power H 70-700     700-1500 L 26-260     260-550 Carriage & Carriage slide Cross slide Stroke 320 mm Carriage slide Stroke 255 mm Lead screw Diameter 38 mm Thread Pitch 6 mm Threads & feeds Threads Inch threads 60 N. 2-112 F.P.P. Metric threads 60 N. pitch 0.2-14mm Diameter threads 50 N. 4-112 D.P. Module threads 50 N. 0.2-7 M.P. Feed Longitudinal feeds NON-BINDING DATA TO BE VERIFIED
