2013 CNC MILLING MACHINE OMV model SHARK 5000

AVAILABLE FROM JULY 2026 YEAR 2013 HEIDENHAIN TNC i530 control TRAVERSING X AXIS 5000 mm Y AXIS 1200 mm Z AXIS 1600 mm Monolithic pallet with surface 5500×1000 mm T-slot dimensions 22 mm Load capacity 6000 kg/mq Rapid traverses X,Y,Z 30,000 mm/min Power supply 400V +/- 10%, 50hz, TN-type network (for other networks a transformer will be quoted) Installed power 60 KVA Compressed air 6 Bars CONTINUOUS TORQUE MECHANICAL HEAD FOR POSITIONING model TMT-50 internal depressurization Max simultaneous axis positioning time 3″ digital AC brushless type maximum speed 7000 g/l’ Nominal power S1 30 kW Maximum power S6 37.5 kW Constant torque S1 400 Nm Maximum torque S6 500 Nm ISO 50-DIN69871 spindle taper Internal lubrication-refrigeration system fully filtered with PAPER FILTRATION -> pressure in feed 25 Bar with flow rate 25l/1′ Tool magazine 40 positions Maximum tool diameter 110 mm Maximum tool length 320 mm Maximum tool weight 15 Kg Removable bulkhead to divide work area with software management that recognizes its presence. The bulkhead can be removed manually via eye bolts fixed above it. Operator platform positioned laterally to the column OVERALL MACHINE DIMENSIONS 13000 x 6186 x 4050 mm MACHINE WEIGHT 40500 Kg NON-BINDING DATA TO BE VERIFIED
