ZANOLETTI OMG 250 SELF-TEACHING LATHE
ZANOLETTI OMG 250 SELF-TEACHING LATHE
Contact us for price
Location:Bergamo, Italy
or
Call +39 02 9475 0001
Description
EUREKA STAMPI LIQUIDATION MARCHENO (BS)
USED MACHINERY
NON-BINDING DATA TO BE VERIFIED
Specifications
| Condition | Used |
| Stock Number | TA275-PF |
| Turning diameter on the bed | 500 mm. |
| Turning diameter on the cross carriage | 250 mm. |
| Rotating diameter on the natural recess | 700 mm. |
| Usable length of natural recess | 360 mm. |
| Pallet width | 340 mm. |
| Asa spindle nose attachment | 6” D1” |
| Spindle hole diameter | 72 mm. |
| Spindle speed min/max | 0÷2000 Gri/min |
| High speed range | 0÷600÷2000 RPM |
| Low speed range | 0÷150÷500 rpm |
| Length of carriage support on the pallet | 670 mm. |
| Cross carriage length | 500 mm. |
| Cross carriage width | 310 mm. |
| Cross carriage race | 345 mm. |
| Rapid movement on carts: | |
| Longitudinal | 10000 mm/mn |
| Transversal | 10000 mm/mn |
| Tailstock quill diameter | 80 mm/mn |
| Tailstock quill stroke | 240 mm/mn |
| C.m. tailstock quill | 5 N |
| Fixed bezel (max. turning diameter) | 210 mm. |
| Spindle motor power | 11 Kw |
| Longitudinal axis engine torque | 10 Nm |
| Cross-axle motor torque | 10 Nm |
| Distance between centers spindle hole baruffaldi turret manual self-centering (year 2025) chip conveyor tool cabinet cnc siemens 810 d | 1.572 Cam lock connection 6″160315 m.mmTAN Ø mm |
| Machine weight | 3700 Kg |
