BTM BAND SAWING MACHINE MOD 61.41 CNC AUTOMATIC 60°DX STROKE 3000

TECHNICAL FEATURES: 90° cutting capacity 610×410- 410 mm 45° cutting capacity 460×250- 410 mm 60° cutting capacity 320×180 - 320 mm Belt dimensions 5200±10 Width 34 mm Thickness 1.1 mm Working table height 870 mm CNC CEB MOZART Blade rotation motor power 2.2 Kw Hydraulic pump power 0.55 Kw Power feeder motor power 0.75Kw Blade speed 22÷120 m\min Cutting descent speed 0÷ 200 m\min Rapid descent speed 3500mm\min Cutting accuracy 0.1 every 100mm Coolant liquid tank 33 L Hydraulic power unit tank 15 L Working pressure 32 Bar Cutting pressure 0÷10 Bar Clamp pressure 32 Bar Vice cylinder stroke 630 mm Feeder carriage stroke 3000 mm Max programmable length 10,000 mm Sawing machine weight 3000Kg Year 2006 State Visible in operation Excellent condition
