2021 GUL Wave Maker G4 Mini Guided Wave Ultrasonic Pipeline Testing System

Guided wave ultrasonic testing system for pipeline inspection, purchased in 2021 and barely used. The system is supplied with a solid-type fixed ring for 6-inch API standard diameters complete with transducer modules (special OD 14 mm), an inflatable-type ring for 6-inch API standard diameters (compatible with API NPS 6", DN 150 mm, OD 168.27 mm), an inflatable-type ring for 8-inch API standard diameters (compatible with API NPS 8", DN 200 mm, OD 219.09 mm), and an inflatable-type ring for 10-inch API standard diameters (compatible with API NPS 10", DN 250 mm, OD 273.05 mm). Also included are 36 HD-series transducer modules (4 transducers each) for inflatable HD rings, 2 additional 12 m connection cables with connectors, 3 user dongles (require reconfiguration with the manufacturer), a Panasonic Toughbook (valued at €1,400, with already-replaced keyboard valued at €600, complete with mouse), and a multiple USB port. The combined new-purchase value of the equipment and accessories exceeds €200,000 (reference value only, not the asking price for this used system). The user dongle requires repurchase from GUL or an authorized Italian or international dealer, along with completion of GUL's required training course to access certain system functions; these are the buyer's responsibility. On-site inspection and evaluation with the seller present is available. Used in pipeline integrity inspection, oil & gas infrastructure assessment, and non-destructive testing for long-range screening of pipe sections for corrosion and defects.

Suitable for

Guided wave ultrasonic testing, pipeline inspection, non-destructive testing, oil and gas pipeline integrity, corrosion detection, NDT equipment, pipeline screening, industrial inspection equipment

Technical Specifications

• Brand: GUL (Guided Ultrasonics Ltd)
• Model: Wave Maker G4 Mini
• Machine type: Guided wave ultrasonic pipeline testing system
• Year of purchase: 2021
• Included rings: Solid-type fixed ring (6" API, special OD 14 mm), Inflatable ring 6" API (NPS 6", DN 150 mm, OD 168.27 mm), Inflatable ring 8" API (NPS 8", DN 200 mm, OD 219.09 mm), Inflatable ring 10" API (NPS 10", DN 250 mm, OD 273.05 mm)
• Transducer modules: 36x HD-series (4 transducers/module) for inflatable HD rings
• Connection cables: 2x additional, 12 m length, with connectors
• User dongles: 3x (require reconfiguration with GUL)
• Computer: Panasonic Toughbook (value €1,400) with replaced keyboard (value €600) and mouse
• Additional accessory: Multiple USB port
• Reference new-purchase value: Over €200,000 (equipment + accessories, informational only)
• Outstanding requirement: User dongle repurchase and manufacturer training course (buyer's responsibility)
• Condition: Used, minimal use since purchase
• Viewing: On-site demonstration available

Contact for price and viewing.

Disclaimer

The above description is provided for informational purposes only. Specifications are based on available information. Buyer is responsible for independent verification prior to purchase.
