2018 DRILLING MACHINE FOR DEEP HOLES SAMAG

DRILLING MACHINE FOR DEEP HOLES SAMAG MODEL TFZ 2L-1000 YEAR 2018 CNC HEIDENHAIN Series Chuck mounting according to DIN HSK 63″ Drilling procedure ELB Maximum drilling depth in a single pass [mm] 1000/1250 Chuck Chuck nominal power 9/13 (S1=100% / S6=40% ED) [kW] 15/23″ Chuck speed continuous [rpm] 6,000 Chuck nominal torque 85/124 (S1=100% / S6=40% ED) [Nm] (128/197) Milling capacity (S1=100%) [cm³/min] 250/475 Threading (larger threads via circular milling) M24 Axis travel X axis (transverse table) [mm] 1600 Y axis (drilling/milling vertical unit) [mm] 1,250 Z axis (drilling/milling horizontal unit) [mm] 1,100 W axis (drilling/milling spindle) [mm] 1,600 A axis (drilling/milling unit, tiltable) [°] +/- 30 X, Y, W and Z axis feed speed [m/min] 20 CNC rotary table CNC rotary table (B axis, 360° rotation) Table surface [mm] 1500 X 1100 Table load (central) [t] 7/10 Cooling system Coolant pressure [bar] MAX. 100/90 Coolant flow rate [l/min] max 40 NON-OBLIGATORY DATA TO BE VERIFIED
