2008 TAKISAWA CNC LATHE model NEX 110

YEAR 2008 N/S CI08N10043 SPINDLE DIAMETER ON THE WORKTABLE mm 495 SPINDLE DIAMETER ON THE MACHINE CAR mm 400 MAXIMUM LATHE DIAMETER mm 400 MAXIMUM LATHE LENGTH mm 657 SPINDLE HOLE DIAMETER mm 75 TRAVEL CARRIES X AXIS mm 220 Z AXIS mm 710 SPINDLE SPINDLE NOSE AS 8″ SPINDLE HOLE mm 86 SPINDLE BORING DIAMETER INTERNAL mm 120 SPINDLE SPEED rpm 35/3,500 SPINDLE POWER KW 18.5/15 TURRET TOOL POSITIONS nr 10 TOOL BAR SECTION mm 25X25 BAR DIAMETER mm 50 FEEDS X AXIS m/min 18 Z AXIS m/min 22 CUTTING FEEDS X AXIS mm/min 0/1,260 Z AXIS mm/min 0/1,260 COUNTER-TLANT TRAVEL COUNTER-TBODY mm 580 TAILSTOCK BAR mm 150 TAILSTOCK DIAMETER mm 110 TAILSTOCK TAPER CM 5 MOTORISATION SPINDLE MOTOR KW 18.5/15 X AXIS SERVO MOTOR KW 1.2 Z AXIS SERVO MOTOR KW 2.5 TANK CAPACITY COOLANT SYSTEM TANK lt 220 HYDRAULIC CONTROL UNIT TANK lt 40 LUBRICATION SYSTEM TANK lt 20 MACHINE OVERALL DIMENSIONS HEIGHT mm 1,755 FOOTPRINT ON FLOOR mm 2,830X1,745 WEIGHT KG 5,000 TOTAL REQUESTED POWER KVA 35 NON-BINDING DATA TO BE VERIFIED
